Explore the Cutting-Edge V-573 Linear Positioning Stages
Revolutionizing Precision Motion Control
The V-573 family of linear positioning stages represents a significant advancement in precision motion control technology, catering to the demanding needs of various industries and research applications. These innovative stages are uniquely designed for tasks such as scanning, measuring, imaging, and alignment, offering exceptional performance in both speed and accuracy.
Exceptional Features of the V-573
With travel ranges of 160mm, 260mm, and 360mm, the V-573 stages are tailored for various applications. The hallmark feature of this stage family is its 1nm absolute encoder resolution, ensuring incredibly precise positioning. The bidirectional repeatability of just 80nm demonstrates its reliability in high-precision tasks, where every movement counts.
Advanced Mechanical Design
The design philosophy behind the V-573 prioritizes guiding precision and operational durability. Engineered with crossed roller bearings, these stages offer excellent straightness and flatness values down to 1µm. This meticulous attention to mechanical integrity guarantees smooth operation and prolongs the lifetime of the stages.
Performance Specifications
- 160/260/360mm travel
- 1nm absolute encoder resolution
- 80nm bidirectional repeatability
- Straightness/flatness up to 1µm
- 500mm/sec maximum velocity
- 1g acceleration capability
- 140N push/pull force
Alongside its impressive specifications, the V-573 can achieve maximum velocities of 500mm/s and configurable acceleration of up to 1g. This fusion of speed and precision makes it an ideal choice for high-demand production environments.
Integration with Advanced Control Systems
The seamless compatibility of the V-573 with PI's ACS-based EtherCAT motion controllers enhances its operational capabilities. By leveraging advanced algorithms, these stages are tuned for optimal performance, reflecting a harmonized synergy between hardware and software.
High Performance in Diverse Industries
The versatility of the V-573 stages allows them to excel across various fields including semiconductor testing, precision micro-assembly, metrology, and laser micro-processing. Additionally, they are invaluable in applications such as high-speed pick-and-place, optical alignment, and medical device manufacturing. Developers in biotechnology and microscopy also rely on these cutting-edge stages for their application needs.
User-Friendly Operation
Equipped with either incremental or absolute encoders, the V-573 stages provide users with flexible options for operation. The absolute encoder models are particularly noteworthy for their capability to deliver 1nm resolution with immediate position feedback right upon power-up. This feature eliminates the need for referencing moves, streamlining the startup process and promoting safe, efficient operation.
Conclusion
The V-573 high-performance linear motor stages are clearly designed for engineers and researchers who demand both accuracy and velocity in their applications. From micro-assembly tasks to high-speed inspections, the reliability and precision of the V-573 make it the standard for modern motion control solutions.
Frequently Asked Questions
What industries can benefit from the V-573 stages?
The V-573 stages are ideal for semiconductor testing, precision micro-assembly, and advanced research across various sectors such as biotechnology and medical device manufacturing.
What is the maximum velocity of the V-573?
The V-573 stages can reach a maximum velocity of 500mm/sec, making them suitable for high-speed applications.
What type of encoders are available with the V-573?
The V-573 is available with both incremental and absolute encoders, offering flexibility for different application requirements.
How is the straightness and flatness performance of the V-573?
The V-573 stages achieve impressive straightness and flatness values of up to 1µm, ensuring high precision in their operation.
What mechanisms ensure the longevity of the V-573 stages?
Crosser roller bearings and a line-contact design minimize friction and wear, contributing to the durability and longevity of the V-573 stages.
