KYOCERA AVX Unveils State-of-the-Art Card-Edge Connectors
The newly introduced 9159-800 Series dual-entry vertical card-edge connectors from KYOCERA AVX set a groundbreaking standard in the industry. Offering a compact above-board height profile, these connectors are crafted to meet the needs of diverse sectors including automotive, transportation, industrial manufacturing, consumer electronics, and appliances.
Innovative Design and Features of the 9159-800 Series
Compact and Versatile
Engineered to address the increasing demand for compact and efficient card-edge connectors, the 9159-800 Series connectors boast a unique form factor equipped with 4–20 field-tested high-strength beryllium copper compression contacts. These contacts are arranged in two rows with a tight pitch of 1mm, ensuring superior space utilization without compromising functionality.
Exceptional Performance Metrics
The gold-plated compression contacts allow for effortless solderless installation, providing impressive current-carrying capacities, rated up to 2A per contact. Their design minimizes contact resistance while ensuring high-reliability electrical and mechanical performance, especially under challenging conditions.
Applications Across Various Industries
The flexibility of the 9159-800 Series connects is evident in its adaptability to several applications. Ideal for automotive infotainment systems, body electronics, and numerous industrial contexts, these connectors are well-suited for automation equipment, sensors, smart home systems, and major appliances.
Durable and Compliant Structure
High-Temperature and Safe Materials
Each connector features insulators made from white glass-filled material designed to withstand high temperatures and is flame-retardant. This ensures longevity and reliability during operation. Furthermore, they are compliant with UL and RoHS standards, making them a safe choice for contemporary electronic needs.
Connection Compatibility
The insulators are designed with stop shoulders which secure proper pad positioning, and the connectors are rated for interfacing with 1.6mm-thick PCBs featuring gold-plated pads. They're perfect for a wide range of use cases, providing users with the versatility they require for modern applications.
Expert Insights from KYOCERA AVX
Marc Actis, Senior Marketing Manager at KYOCERA AVX, expressed enthusiasm for the new series, noting, "Our card-edge connector offerings have evolved over decades, reflecting ongoing research and field-tested performance in numerous applications. The 9159-800 Series enhances our product lineup, providing customers with an unparalleled mix of space savings, performance, and flexibility for various markets."
With the increasing exploration of compact technologies, KYOCERA AVX is leading the way in providing solutions that cater to performance and space-efficient design. This innovative series is poised to redefine industry standards.
Frequently Asked Questions
What are the key features of the 9159-800 Series connectors?
The 9159-800 Series connectors feature a low above-board height, solderless installation, and are rated for up to 2A per contact with low resistance.
What industries can benefit from these connectors?
These connectors are suitable for automotive, industrial manufacturing, consumer electronics, and appliance sectors among others.
Are the connectors compliant with safety standards?
Yes, they are UL and RoHS compliant, ensuring safety and reliability in various applications.
How does the installation of these connectors work?
The connectors enable easy solderless installation thanks to their unique design and gold-plated contacts which enhance performance.
Can these connectors be used in harsh environments?
Yes, they are engineered for high reliability and mechanical performance under harsh conditions, making them ideal for challenging applications.
