Introducing the CP2816 Series High-Directivity Couplers
KYOCERA AVX has unveiled its latest innovation, the CP2816 Series integrated thin film (ITF) high-directivity couplers. These couplers are engineered to fulfill the increasing demand for compact, high-power couplers that can operate effectively within VHF and UHF bands.
Design Features and Performance
The CP2816 Series is specially designed with a compact and low-profile 2816 (7x4mm) case. These couplers are robust enough to handle 20W of continuous power while maintaining a 50? impedance, ensuring excellent high-frequency performance across a frequency range of 225–750MHz. They function efficiently even under extreme temperatures, with operational capabilities ranging from -40°C to +105°C.
Coupling and Reliability
Providing a tight coupling factor at specified levels (-10±1.2dB, -10±2dB, -15±2dB, and -15±4dB), these couplers feature low insertion loss measured from under -0.8dB to less than -0.9dB, a VSWR of 1.3, and remarkable directivity at -14dB. Additionally, the CP2816 Series guarantees high temperature stability and reliability.
Applications Across Various Industries
Ideal for high-frequency wireless applications, the CP2816 Series couplers serve a multitude of markets, including telecommunications, commercial aerospace, military and defense, and automotive sectors. They are particularly suited for deployment in active antennas, base stations, emergency systems, VHF and UHF radios, radar systems, and testing apparatus. This versatility makes them an essential component for ensuring effective RF performance.
Expert Insights on Market Needs
Mohammed Abu-Naim, the RF Product Manager at KYOCERA AVX, highlighted the relevance of these new couplers in responding to market dynamics. He mentioned, "Our new CP2816 Series couplers meet the growing need for compact, high-power solutions tailored for microwave and RF systems. RF engineers face challenges in designing smaller, powerful circuits, and our couplers ensure that power specifications are met, safeguarding against potential damage from return power."
Manufacturing Excellence and Compliance
The couplers boast nickel land grid array (LGA) terminations with lead-free soldering capabilities, supporting various soldering processes like reflow, wave, and vapor phase. Furthermore, they are RoHS compliant, adhere to IATF 16949 standards, and are manufactured in an ISO-9001 certified facility. Their packaging on tape and reel provides reliable assembly convenience.
How to Learn More and Place Orders
For detailed information about the CP2816 Series high-directivity couplers, interested parties can visit the official KYOCERA AVX website. Orders can be conveniently placed through major electronic component distributors. KYOCERA AVX is dedicated to providing comprehensive solutions to meet customer needs in the rapidly evolving technology landscape.
Frequently Asked Questions
What is the CP2816 Series mainly designed for?
The CP2816 Series is designed for high-frequency wireless applications across various sectors including telecommunications and aerospace.
What power handling capabilities do the CP2816 couplers support?
These couplers can handle continuous power levels of up to 20W.
What is the temperature range in which the CP2816 Series operates?
The couplers operate effectively within a temperature range from -40°C to +105°C.
What are the key benefits of using the CP2816 Series?
Benefits include high reliability, low insertion loss, excellent high-frequency performance, and compliance with industry standards.
Where can I buy the CP2816 Series couplers?
The couplers can be purchased through major electronic component distributors such as DigiKey and Mouser Electronics.
